VxRAIL 0

VxRail – Lookup Service Tag/Serial Number

See also related Post: https://davidring.ie/2019/09/18/vxrail-lookup-model-psnt/ In addition to the physical tag at the front of the VxRail appliance you may also leverage PowerCLI, ESXi console or vCenter GUI to pull the ST/SN of each VxRail appliance. PowerCLI Get-Hosts -Server VxRailManager_IP -Username administrator@vsphere.local -Password PW |ft sn, hostname ESXi Console Per individual host: /opt/vxrail/tools/ipmitool fru print 17 vCenter UI With the […]

VxRAIL 1

VxRAIL – Installing API PowerShell Modules

One method of consuming the available VxRail APIs is by leveraging the VxRail API PowerShell Modules Package from within your Windows OS using PowerShell. Each public API has a corresponding PowerShell cmdlet included in the VxRail PowerShell modules starting with VxRail 4.7.300. The API User Guide can be found here: https://support.emc.com/docu91468_VxRail-Appliance-4.5.x,-4.7.x,-and-7.0.x-API-Guide.pdf?language=en_US Steps to install the VxRail API PowerShell Modules Package […]

Dell EMC 0

Dell EMC Networking – Configuring Layer-2 Mode

Switch model: S4048-ON Code Version: 9.10(0.1) 48 Ten GigabitEthernet/IEEE 802.3 interface(s)6 Forty GigabitEthernet/IEEE 802.3 interface(s) Brief detail in relation to setting Layer-2 switchport mode on all 48x10GbE ethernet interfaces to support L2 VLAN based networking: cork-vxrail1-tor#conf tcork-vxrail1-tor(conf)#interface range tengigabitethernet 1/1-1/48cork-vxrail1-tor(conf-if-range-te-1/1-1/48)#switchportcork-vxrail1-tor(conf-if-range-te-1/1-1/48)#no shutcork-vxrail1-tor(conf-if-range-te-1/1-1/48)#exitcork-vxrail1-tor(conf)#exitcork-vxrail1-tor# To revert to non switchport mode: cork-vxrail1-tor#conf tcork-vxrail1-tor(conf)#interface range tengigabitethernet 1/1-1/48cork-vxrail1-tor(conf-if-range-te-1/1-1/48)#no switchportcork-vxrail1-tor(conf-if-range-te-1/1-1/48)#exitcork-vxrail1-tor(conf)#exitcork-vxrail1-tor#

Dell EMC 0

Dell EMC Networking – Configuring MTU

Switch model: S4048-ON Code Version: 9.10(0.1) 48 Ten GigabitEthernet/IEEE 802.3 interface(s)6 Forty GigabitEthernet/IEEE 802.3 interface(s) Brief detail in relation to setting an MTU (Maximum Transmission Unit) value on all 48x10GbE ethernet interfaces to support Jumbo Frames: cork-vxrail1-tor#conf tcork-vxrail1-tor(conf)#interface range tengigabitethernet 1/1-1/48cork-vxrail1-tor(conf-if-range-te-1/1-1/48)#mtu 9216cork-vxrail1-tor(conf-if-range-te-1/1-1/48)#exitcork-vxrail1-tor(conf)#exitcork-vxrail1-tor#show interfaces tengigabitethernet 1/1 | grep MTUMTU 9216 bytes, IP MTU 9198 bytescork-vxrail1-tor# To revert to default MTU value […]

VxRAIL 0

VxRail 7.0 – Useful Log File Information

The following log files can be accessed either via console or SSH to VxRail Manager. Useful VxRail Manager 7.0.010+ Log Files Note: SLES15 is the OS used for VxRail Manager. Monitor VxRail bring-up logs: dayone.log , short.term.log & firstboot.log: dayone.log – detailed information in relation to initial first run configuration. (/var/log/microservice_log/dayone.log) short.term.log – micro services related information. (/var/log/microservice_log/short.term.log) firstboot.log – detailed information […]
