DellEMC EHC – ‘Onboarding A Local Cluster’ (Part 1)

The following two-part post details how to add an Enterprise Hybrid Cloud (EHC) vSphere Local Cluster, in EHC terms we refer to this cluster type as LC1S (Local Copy on One Site) other EHC cluster types include:

VS1S – vSAN Storage on One Site (not used by STaaS)
CA1S – CA VPLEX Metro Storage on One Site
CA2S – CA VPLEX Metro Storage across Two Sites
DR2S – DR RecoverPoint Storage across Two Sites

For details on how to add other cluster types please refer to the EHC Admin Guide:

ENTERPRISE HYBRID CLOUD 4.1.2 Administration Guide

There are a number of prerequisites required in advance of running the Onboard Cluster workflow in EHC, namely:

  • Add a Site
  • Add a vCenter
  • Add a Hardware Island

Part 1 will address the first two prerequisites (Add a Site, Add a vCenter).

The below flowchart details nicely what is required in terms of prerequisites and is provided for throughout the EHC Admin Guide for the various cluster types (thanks @LifeOfBrianOC):

AddSiteFlow1

Note: this post provides an example and does not substitute for the EHC Admin Guide. Continue reading

Dell EMC – Enterprise Hybrid Cloud (EHC) 4.1.2

EHC LOGO

EHC (Enterprise Hybrid Cloud) which is the DellEMC turnkey VMware (vRealize Suite) based cloud offering has made great strides in recent releases transforming the cloud strategy for CPSD CI/HCI, namely EHC on VxBlock/VxRack Flex/VxRail (Engineered, manufactured, managed, supported and sustained as one product) and this release is no different with massive improvements around automation especially in relation to both the Install and Upgrade process associated with the EHC platform on VxRail leading to far quicker and more seamless deployments of the EHC stack. Enhanced multi-site capabilities, DRaaS offering on VxRail and factory delivered EHC on VxRack Flex w/NSX are some of the biggest milestones with this release. Continue reading

EHC 4.1: ESXi Host Migration Process (vCenter Host Migration with ViPR Export Groups)

This procedure details the steps to execute in order to remove an ESXi host from a source ViPR Export Group and add to an existing target Export Group.

Note: this procedure applies to ViPR 3.0 and below, ViPR 3.6 introduces a more automated procedure which I intend to cover in a future post.

Host Removal – remove ESXi Host from a ViPR Export Group

Please ensure there are no EHC StaaS or VIPR native tasks being executed while performing the following procedure.

Note: Ensure the version of SMI-S complies with the EHC ESSM stated version.

The following steps detail the procedure for removing a host from a vSphere ESXi cluster in vCenter and utilizing the ViPR CLI to remove the same host from the cluster Export Group. Continue reading

VxRail – Welcome Enterprise Hybrid Cloud (EHC)

Introducing ‘EHC on VxRail’!

VxRAILEHC

Introduced as part of the EHC 4.1.1 release (Code named “Challenger”) – GA March ’17

Simple, Easy, Start Small, Scalable!

VxRAIL HCI Appliance now has the option of including the ‘Enterprise Hybrid Cloud 4.1.1’ platform as part of an automated greenfield installation. Thousands of hours of engineering, designing, testing and validation has gone into this release with a laser focus on delivering an automated ‘EHC on VxRail’ onsite installation. Engineered on the VxRail P470(F) Appliances, ‘EHC on VxRail’ offers a lighter weight and smaller footprint hybrid cloud solution from where you can start small and scale exponentially. Continue reading

DellEMC EHC 4.x ‘Hybrid Management Model’ (VxBlock/VxRack)

This post provides a high level overview of the Enterprise Hybrid Cloud 4.x ‘Hybrid Management Model’which is the default model used for VxBlock & VxRack EHC solutions.

The following DellEMC acronyms are used throughout this post:

EHC =  Enterprise Hybrid Cloud
CPSD = Converged Platforms & Solutions Division
AMP = Advanced Management Pod
ESSM = EMC Simple Support Matrix
RCM = Release Certification Matrix
vCSA = vCenter Server Appliance
CI = Converged Infrastructure
HCI = Hyper Converged Infrastructure
LCS = Logical Configuration Survey

The images used in this post were taken from the EHC Architecture Guides, for more detailed architectural explanations please refer to the following EHC 4.1 Architecture Guides:

EHC Reference Architecture Guide

EHC Concepts and Architecture Guide

Continue reading

ViPR Controller -Configuring AD Authentication

The default built-in administrative accounts may not be granular enough to meet your business needs, if this is the case then adding an authentication provider such as Active Directory which we highlight as part of this configuration allows you to assign users or groups to specific roles.

The example configuration provided here was part of an Enterprise Hybrid Cloud solution. Continue reading
